Circular Wire Rope Isolators

Circular Wire Rope Isolators
Circular Wire Rope Isolators
Product Code : JGX-108-1000
Brand Name : Hoan
Product Description

Bestowed by ISO 9001:2008 certification, we are occupied in manufacturing, exporting and supplying an assorted array of Circular Wire Rope Isolators. The offered isolators are widely appreciated owing to their rugged design and high load bearing capacity. In order to manufacture these isolators, our deft professionals use quality-tested basic materials with the aid of ultra-modern techniques. Besides, the provided Circular Wire Rope Isolators are available in various technical specifications at the most competitive prices.

    Circular Wire Rope Isolators are stable mounting assemblies of high quality stainless steel stranded wire rope held with rugged metal retainers. Each isolating element has specific response characteristic determined by the diameter of the steel wire rope, the number of strands, the cable length, the cable twist or lay, and the number of cables per section.

    Inherent damping is provided by flexure hysteresis, i.e., the rubbing and sliding friction between the strands of the steel wire rope.

    Our Circular Steel Wire Rope Isolators are Anti Vibration Shock Mounts which provide higher levels of isolation than any other medium or design, with excellent vibration damping. Stainless Steel Cable Mounts are truly unique, adapted to a spectrum of physical and engineering requirements so broad that it includes almost every isolation need. They have put to rest the notion that a single mount cannot handle both shock and vibration.

    Series JGX stainless steel wire rope isolators, feature 3-dimension variable stiffness and variable damping, which provide excellent vibration and shock isolation in harsh environments in a practically unlimited range of applications  aircrafts, ships, tanks, oilfield logging truck.

    Designed for restraining the interference of DC power cable, Series JGX wire rope isolators feature excellent common mode and differential mode filter performance, which have been widely using in many kinds of electronic equipments which have AC/DC, DC/AC, DC/DC switch converter or use DC as its power.

    The static load bearing range is from 1kg to 1T, which meets many kinds of requirements and demands from our clients and gets stable customers royalty after their launch into domestic market.

    Key Features/Benefits:

    • High Performance Shock And Vibration Isolation
    • Exceptional Reliability And Long Span Life
    • High Damping
    • Broad Temperature Range
    • No Ageing
    • Corrosion Resistant (Unaffected By Oils, Fuels, And Chemicals, Etc.)
    • Great Adaptability/Versatility
    • Corrosion Resistance
    • Easy To Install
    • High Pressure Resistance
    • Sturdy Construction

    Technical Data of JGX-108-1000 wire rope isolator:

    • L (mm): 370
    • W (mm): 165
    • H (mm): 152
    • Max Static Load (kg): 1,000
    • Material of Mount Bar: 304 Stainless Steel
    • Material of Cable: 304 Stainless Steel

    Custom configurations (material, size, plating, or number of loops, etc.) available upon request
